PRODUK |
Model |
FM 260 JD |
PRODUKSI |
Kode Produksi |
FM8JNKD-RGJ |
PERFORMANCE |
Kecepatan Maksimum(km/jam) |
86 |
|
Daya Tanjak (tan Ø) |
47.1 |
MESIN |
Model |
J08E-UF |
|
Tipe |
Diesel 4 Stroke; In-Line |
|
Tenaga Maks (PS/rpm) |
260 / 2500 |
|
Momen Putir Maks. (Kgm/rpm) |
76 / 1500 |
|
Jumlah Silinder |
6 |
|
Diameter x Langkah Piston (mm) |
112 x 130 |
|
Isi Silinder |
7684 |
KOPLING |
Tipe |
Single Dry Plate, with Coil Spring |
|
Diameter |
380 |
TRANSMISI |
Tipe |
ZF-9S1115TD |
|
Perbanding Gigi |
– |
|
ke-1 |
12.728 |
|
ke-2 |
8.829 |
|
ke-3 |
6.281 |
|
ke-4 |
4.644 |
|
ke-5 |
3.478 |
|
ke-6 |
2.538 |
|
ke-7 |
1.806 |
|
ke-8 |
1.335 |
|
ke-9 |
1 |
|
mundur |
12.040 |
KEMUDI |
Tipe |
Integral Power Steering |
|
Radius Putar Min. (m) |
8.8 |
SUMBU |
Depan |
Reverse Elliot, |
|
Belakang |
Full floating type with hypoid gear |
|
Perbandingan gigi akhir |
STD = 6.428 |
|
Sistem Penggerak |
Rear 6×4 |
REM |
Rem Utama |
Air Over Hydraulic, |
|
Rem Pelambat |
With on Exhaust Pipe |
|
Rem Parkirr |
Internal Expanding tipe pada transmisi output |
RODA & BAN |
Ukuran Rim |
20X7.00T-162 |
|
Ukuran Ban |
10.00-20-16PR |
|
Jumlah Ban |
10 |
SISTIM LISTRIK |
Accu |
12V-65Ah x2 |
TANGKI SOLAR |
Kapasitas (L) |
200 |
DIMENSI (mm) |
Jarak Sumbu Roda |
4130+1300 |
|
Panjang bak |
6420 |
|
Total Panjang |
8480 |
|
Total Lebar |
2450 |
|
Total Tinggi |
2700 |
|
Lebar Jejak Depan FR Tr |
1930 |
|
Lebar jejak Belakang RR Tr |
STD:1855(JIS-8) |
|
Julur Depan FPH |
1255 |
|
Julur Belakang ROH |
1795 |
SUSPENSI |
Depan & Belakang |
Rigid Axle with Semi Elliptic |
BERAT CHASSIS (kg) |
Depan |
2900 |
|
Belakang |
3710 |
|
Berat Kosong |
6610 |
|
GVWR |
26000 |
TIPE KAROSERI |
Dump |
O |
|
Mobil Boks |
O |
|
Boks Berpendingin |
O |
|
Bak Terbuka |
O |
|
Crane |
O |
|
Mobil Derek |
O |
|
Sky Lift |
– |
|
Tangki |
O |
|
Los Bak |
O |
|
Angkut Kendaraan |
– |
|
Truk Logging |
O |
|
Molen |
– |
|
Tangki High Blow |
O |
|
Arm Roll |
– |
|
Mobil Pemadam |
– |
|
Ambulance |
– |
|
Truk Sampah |
– |
|
Mobil Penarik |
– |
